Quality Testing Electrical Properties



Electrical testing of thermoset composites verifies that these materials can safely insulate against electrical currents, resist short circuits, and endure high voltages without degrading. This testing is essential for confirming material reliability and meeting strict safety standards in high‑voltage, industrial, and aerospace environments.

Industrial laminates in Labatory settings.
Electrical Properties
Electrical performance is one of the defining characteristics of high-quality thermoset composites. At Acculam, our in-house laboratory performs comprehensive electrical testing to evaluate insulation performance, dielectric properties, arc resistance, and other critical electrical characteristics. These tests verify that our materials meet the demanding performance and reliability requirements of applications in power generation, electrical distribution, electronics, industrial equipment, and other high-voltage environments.

Dielectric Breakdown Voltage: Dielectric breakdown voltage measures the point at which an insulating material can no longer resist an applied electrical field and becomes conductive.

  • Equipment: Breakdown voltage tester. This test helps determine the maximum voltage a material can withstand before electrical failure occurs.

Dielectric Strength: Dielectric strength evaluates a material's ability to function as an electrical insulator under high voltage conditions. Results are typically expressed as voltage per unit thickness and indicate how effectively a material resists electrical breakdown.

  • Equipment: Breakdown voltage tester

Dry Arc Resistance: Dry arc resistance testing measures a material's ability to withstand repeated exposure to electrical arcing along its surface without degrading or forming a conductive path. This property is especially important for electrical insulation components operating in high-voltage environments.

  • Equipment: Dry arc resistance tester

Comparative Tracking Index (CTI): The Comparative Tracking Index (CTI) assesses a material's resistance to surface tracking caused by moisture, contaminants, and electrical stress. Higher CTI values indicate improved performance and reliability in demanding electrical applications.

  • Equipment: Comparative Tracking Index tester

Hot Wire Ignition (HWI): Hot Wire Ignition testing evaluates a material's resistance to ignition when exposed to a heated wire or overheated electrical component. The results help determine a material's suitability for electrical and electronic applications where abnormal operating conditions may occur.

  • Equipment: Hot Wire Ignition tester

High Current Arc Ignition (HAI): High Current Arc Ignition testing measures a material's ability to resist ignition when subjected to the intense heat generated by a high-energy electrical arc. This evaluation provides insight into the material's performance in environments where electrical faults may occur.

  • Equipment: High current arc ignition tester

Glow Wire Ignitability (GWI): Glow Wire Ignitability testing assesses a material's resistance to ignition when exposed to a heated element that simulates an overheated electrical connection. The results help verify material safety and fire resistance in electrical and electronic applications.

  • Equipment: Glow wire -Ignitability tester

Surface Resistance: Surface resistance measures the ability of a material's surface to resist the flow of electrical current. This property is critical for applications requiring effective insulation and protection against unintended electrical leakage.

Equipment:

Dielectric Constant: Dielectric constant, also known as relative permittivity, measures a material's ability to store electrical energy within an electric field. This property influences the electrical performance of insulating materials used in power distribution, electronics, and high-voltage applications.

  • Equipment: Dielectric constant dielectric loss tester

Dissipation Factor: Dissipation factor measures the amount of electrical energy that is converted into heat when an insulating material is subjected to an alternating current (AC) electrical field. Lower dissipation factors generally indicate more efficient electrical insulation and reduced energy loss.

  • Equipment: Dielectric constant dielectric loss tester
